TownSteel - E-Kontos 5000RF Smart Motorized Mortise Lock with Cylinder & WiFi System - Clutched Lockbody - Grade 1

The e-Kontos 5000RF Series electronic mortise lock is a Grade 1 ANSI/BHMA A156.13 certified standalone access control solution built for superior security and durability. Designed with an integrated keypad and escutcheon trim, this electronic lockset delivers reliable keyless entry without the need for a centralized system. Ideal for rental properties, residential homes, hospitals, hotels, and office buildings, the e-Kontos 5000RF Series combines modern design, high performance, and commercial-grade security. Must pair with RF gateway to go online; gateway sold separately.

Features:
  • Illuminated 12-pin touchpad
  • Use Wi-Fi gateways to extend remote access
  • 400 user codes Interchangeable with RFID keycards/stickers
  • Escutcheon design
Specifications:
Series RF (WiFi)
Lockbodies Rigid, Clutched, Auto Deadbolt
Levers Sentinel or Quest, others upon request
Finish 622 (US19) and 626 (US26D), others upon request
Cylinder SC (Schlage C keyway), SFIC / SLFIC / CLFIC with/without core, or high security
ANSI/BHMA A156.13 Grade 1 certified
ANSI/BHMA A156.25 Meets industry standards
UL/ULC UL 10C 3-hour rated
BAA Meets guidelines of the Buy American Act
FCC FCC Part 15 certified
Handings LH / RH / LHR / RHR, field reversible
Door Thickness 1-3/4" (others upon request)
Backsets 2-3/4"
Strike ANSI strike, stainless steel or plated
Lever Parameters Return less than 1/2" (dependent on lever selection)
Deadbolt 1" throw, stainless steel, anti-saw hardened pins
Latch Bolt 3/4" projection, stainless steel, split
Certifications ANSI/BHMA A156.13, A156.5 Grade 1 Certified;
ANSI/BHMA A156.25 Meets Industry Standards;
UL 10C 3-hour;
FCC Part 15
Compliance Meets requirements of the Americans with Disabilities Act (ADA);
Meets guidelines of the Buy American Act (BAA)
