Sargent
Sargent - 8265 - Privacy Bath/Bedroom Mortise - Less Cylinder - Rose Trim Function - Grade 1
Sargent - 8265 - Privacy Bath/Bedroom Mortise - Less Cylinder - Rose Trim Function - Grade 1
Regular price
$542.56 USD
Regular price
$667.35 USD
Sale price
$542.56 USD
Unit price
per
Couldn't load pickup availability
Sargent - 8265 - Privacy Bath/Bedroom Mortise - Less Cylinder - Rose Trim Function - Grade 1
The 8200 Series mortise lock is designed and constructed with the highest quality components to provide maximum security, performance, and durability, making it the strongest lock on the block. Considered the industry benchmark for all mortise locks on the market today, the robust lock is an attractive solution with a multitude of lever and escutcheon styles available
Features:
- ANSI/BHMA Grade 1 certified for cycle and strength requirements
- UL-cUL listed for 3 hour fire fdoors and windstorm applications
- Thru-bolted lever trim and strengthened cylinder retainer
- 10-year Manufacturer warranty
- Patented design and construction
Product Specifications:
| Manufacturer | Sargent |
| Grade | Grade 1 |
| BAA Qualified | Yes |
| Manufacturer Warranty | 10 Years |
| Fire Rating | 2 Hours {B} |
Technical Specifications:
| Handing | Field Reversible |
| Screws | Combination |
| Cylinder Type | Less Cylinder |
| Std. Strike Height | 4-7/8 Inch |
| Std. Strike Width | 1-1/4 Inch |
| Lever Design | J, L |
| Std. Latch Type | Spring Latch (Unguarded) |
| Std. Latch Backset Dim | 2-3/4 Inch |
| Door Thickness | 1-3/4 Inch |
| Lock Face Size | 8 x 1-1/4 Inch |
| Std. Strike Number | 82-0110 |
| Std. Strike Type | ASA Strike |
| Rose Design | LN Rose |
| ANSI Function | F22 - Privacy |
| Function | 65-Privacy Bath/Bedroom |
| Bolt Projection | 3/4 Inch Latch |
Benefits:
- Strength and Reliability: Far exceeds independently verified testing, making it the strongest and most durable mortise lock in the industry. Verified for over 14 million cycles.
- Security: Several security features provide additional resistance against vandalism and unauthorized entry.
- Flexibility and Aesthetics: Aesthetic design combined with a variety of functions, lever designs and architectural finishes match a wide range of styles and make it ideal for all types of applications (e.g. offices, hospitals, behavioral health environments, schools/universities)
- Ease of Install and Maintenance: Multifunctional lockbody makes switching functions on-site easy and reduces inventory requirements.
Installation Video:
