KeyInCode KIC2500-SGR Single Gang Box MiFare Card Reader 6.4
The KIC2500 Single Gang Box MiFare Card Reader 6.4 is a mobile-ready contactless smartcard reader designed for single-gang wall box installations. Ideal for interior and exterior access points, it combines sleek aesthetics with robust performance, offering secure credential reading via both smartcard and Bluetooth Low Energy (BLE) mobile access.
Specifications:
| Supported Technologies | Contactless smartcard and Bluetooth Low Energy (BLE) |
| Mounting | Fits standard single-gang wall box and flat surfaces |
| Dimensions | 3.0" W x 4.6" H x 0.75" D (76 mm x 117 mm x 19 mm) |
| Voltage Range | +8 to 14 VDC |
| Current Draw | 60 mA typical, 250 mA peak @ 12 VDC |
| Read Range | Physical Credentials: Up to 2" (51 mm), Mobile Credentials: Up to 15 ft (4.6 m) |
| LED Indicators | Four-state (Red, Green, Amber, Off) |
| Audio | Built-in beeper |
| Environmental Ratings | IP67 rated (dust and water-resistant) |
| Operating Temperature | -31 F to 140 F (-35 C to +60 C) |
| Operating Humidity | 0% to 90% RH |
| Color | Black (snap-on cover included) |
| Certifications | FCC, IC, CE, UL294, ULC 60839-11-13 |
| Cabling Requirements | 24 AWG minimum, multi-conductor stranded, foil shielded |
