ILCO Mechanical Edge Cut Key Duplicator Machine Flash 008 / Key Cutting Machine

ILCO Mechanical Edge Cut Key Duplicator Machine Flash 008 / Key Cutting Machine

Lightweight, Compact, Portable��� this mechanical, edge cut key duplicator model is an ideal choice for on-site, mobile jobs or counter tops where space may be limited. The Flash 008 will easily duplicate most edge cut cylinder, cruciform, large bow and long blade keys; including the larger, oversize style automotive keys.

Features:

• Four sided, nickel plated jaws for clamping the majority of all edge cut/flat type keys
• Smooth jaw rotation by simply twisting into position
• Slotted jaw surfaces accommodate tip stop bars and rigid shoulder gauge design allow for greater accuracy when loading and gauging keys
• Wide spacing 3 1/2��� (88.9 mm) spacing between clamps accommodate large bow (head) and long blade keys, including flip style keys
• Depth tracer system with micro adjustment for precise calibration
• AlTiN (Aluminum Titanium Nitride) coated cutter for longer life and oxidation resistance even at temperatures up to 800��
• Nylon deburring brush
• Electromagnetic ���main��� safety switch with separate cutter motor switch for easy access.
• Mounting bracket included for securing the machine to counter
• Two year warranty

Technical Data & Specifications:

• Power Supply: 120V-60Hz
• Maximum absorbed power: 1.2 Amp, 130 Watt
• Cutter motor: single phase and speed
• Movements: by rectified carriage shaft and rack
• Tool Speed: 2900 rpm
• Carriage Runs: 1.65��� (42 mm)
• Cutter: AlTiN coated
• Brush: Nylon
• Dimensions: Width: 12.2��� (310 mm) Depth: 9.5��� (240 mm) Height: 8.7��� (200 mm)
• Weight: 14 lbs. (6.4 kg)

Downloads:

• Flash-008 Brochure-English
• Flash-008 Brochure-Espa��ol
• Flash-008 Manual-English
• Flash-008 Manual-Espa��ol
• Flash-008 120-60 Spare Parts-English
