Falcon

Falcon - K511PD - Push-Turnbutton Entrance Cylindrical Lock with ASA Strike and 2 3/4 Backset - Grade 2 - 626 (Satin Chrome Finish)

Falcon - K511PD - Push-Turnbutton Entrance Cylindrical Lock with ASA Strike and 2 3/4 Backset - Grade 2 - 626 (Satin Chrome Finish)

$160.98 USD
$193.18 USD $160.98 USD
Sale Sold out

Falcon - K511PD - Push-Turnbutton Entrance Cylindrical Lock with ASA Strike and 2 3/4" Backset - Grade 1 - 626 (Satin Chrome Finish)

K Series Grade 1 Cylindrical Lever Locks

Conventional cylinders and small format interchangeable cores that are compatible with SFIC products from other manufacturers.

Feature:
  • Clutching lever design allows the lever to move when locked without unlatching the door, preventing damage to the chassis
  • Four screws through-bolted for added strength, providing high security and peace of mind
  • Lever security caps to help prevent undesired lever removal and lever sag after continual use
  • Conventional cylinders or interchangeable core keying compatible with SFIC products from Falcon or other manufacturers.
  • Non-handed levers for easy field installation
Product Specifications:
Vendor Allegion
Manufacturer Falcon
SKU K511PD Q 626
UID FALK511PDQ626
Grade Grade 1
Installation Commercial
Origin China
Unit of Measure Each
Base Material Brass, Bronze
UL Listing Type ANSI A156.2-2011, Series 4000, Grade 1, UL Listed
ANSI Number F109
Fire Rated 3 Hours {A}
Technical Specifications:
Function K511-Entry/Office Lock
Function Family Entrance
ANSI Function F109 - Entry/Office
Lever/Knob Design Q - Quantum Lever
Lever/Knob Design Family Curved Lever
Rose/Escutcheon Design 3-1/2" Rose Diameter
Rose/Escutcheon Dimensions 3-1/2"
Cylinder Type Conventional Cylinder
Num Pins 6
Key(s) Cut
Num of Keys 2
Handing Non-handed
Door Thickness 1-3/4" to 2-1/8"
Std. Latch Number 30-302
Std. Latch Type Deadlatch
Std. Latch Backset Dim 2-3/4"
Latch Bore Diameter 1"
Lock Face Size 1-1/8" x 2-1/4"
Bolt Projection 1/2"
Bore Hole Diameter 2-1/8"
Std. Strike Number 30-148
Std. Strike Type ASA Strike
Std. Strike Height 4-7/8"
Std. Strike Width 1-1/4"
Screws Wood/Metal Screws
Product Type Cylindrical Lock
