Dexter - C2000 Series Cylindrical Lock - Passage Function - Grade 2

The Dexter C2000 series is a grade 2 cylindrical lockset that is offered in 3 trims and 4 finishes.

Features:
  • 1 3/8" to 1 3/4" door range standard
  • Brass (605) ball knobs come packaged with square-corner beveled latch with 2 3/8" backset and ANSI 1 1/4" x 2 1/4" T-Strike standard.
  • All other functions (except dummy) include 1 1/8" x 2 1/4" square-corner beveled latch with 2 3/4" backset and ANSI 1 1/4" x 4 7/8" curved lip strike (30-148)
  • Schlage C cylinders are 6-pin cylinders keyed 6, keyed different
  • Accommodate SFIC to accept 6-pin/7-pin
Product Specifications:

Vendor Allegion
Manufacturer Dexter
Grade Grade 2
Installation Commercial
Unit of Measure Each
Base Material Brass
UL Listing Type ANSI A156.2 Series 4000, Grade 2, UL Listed
Fire Rated 3 Hours {A}
Burglar Rated No

Technical Specifications:

Function Passage
ANSI Function F109 - Entry/Office
Lever/Knob Design Ball Knob / Regular
Lever/Knob Design Family Ball Knob
Rose/Escutcheon Design 3" Rose Diameter
Rose/Escutcheon Dimensions 3"
Cylinder Type Conventional Cylinder
Num Pins 6
Std. Keyway C
Key(s) Cut
Num of Keys 2
Handing Non-Handed
Door Thickness 1-3/8" to 1-3/4"
Std. Latch Number C2000-DL-605
Std. Latch Type Deadlatch
Std. Latch Backset Dim 2-3/8"
Latch Bore Diameter 1"
Lock Face Size 1" x 2-1/4"
Bolt Projection 1/2"
Bore Hole Diameter 2-1/8"
Std. Strike Number C2000-TS
Std. Strike Type T-Strike
Std. Strike Height 2-3/4"
Std. Strike Width 1-1/4"
Screws Wood/Machine Screws
Product Type Cylindrical Lock
