Camden CX-ED1079D-BK Standard Depth ANSI Universal Electric Strike - 5/8" to 3/4" Throw - Grade 1
Camden CX-ED1079D-BK Standard Depth ANSI Universal Electric Strike - 5/8" to 3/4" Throw - Grade 1
Regular price
$351.43 USD
Regular price
$468.57 USD
Sale price
$351.43 USD
Unit price
per
Couldn't load pickup availability
Camden CX-ED1079D-BK Standard Depth ANSI Universal Electric Strike - 5/8" to 3/4" Throw - Grade 1
Standard Depth Grade 1 'Universal' electric strike, 5/8" to 3/4" throw, 12/24V AC/DC, fail safe/fail secure operation, horizontal adjustment, and 3 black faceplates (CX-ESP1B-BK, CX-ESP3B-BK & CX-ESP4B-BK).
Features:
- Centerline latch entry for cylindrical locksets.
- Adjustable strike body
- Selectable 12/24V AC/DC
- Selectable fail safe / fail secure operation
- 3 black faceplates included
- Horizontal adjustability of strike faceplate/body Non-handed
- Easy fit connectors for power & monitoring wires
- Trim plate included
- Non-handed
- Continuous duty operation
Specifications:
| Voltage | 12/24V AC/DC |
| Current Draw | 260 mA @ 12 VDC 150 mA @ 24 VDC |
| Static Hold Strength | 1,500 Lbs. |
| Dynamic Strength | 70 Ft-Lbs. |
| Endurance | 1,000,000 cycles (Factory Tested) 250,000 cycles (UL Verified) |
| Mode | Selectable - Fail Safe; Fail Secure |
| Operation | AC - Buzz DC- Silent |
| Duty | Continuous |
| Mechanical Adjustment | Strike body |
| Latch Monitor | No |
| Dimensions | 3.25"L x 10.51"W x 2.25"H |
