ABRITES - ML001 - Advanced Diagnostics for McLaren Vehicles

ABRITES - ML001 - Advanced Diagnostics for McLaren Vehicles

The first Abrites license for McLaren vehicles tone for a new range of functionalities for your AVDI! It is the continuation of our work on supercars, presenting you with even more opportunities to develop your business!

Features:

• All-Abrites solution for McLaren!
• All by OBD!
• No third-party tools required!

The ML001 allows you to calibrate various modules and align both vehicle and gateway configuration. It also includes multiple guided and coding functions.

Functionalities:

• Gateway configuration change
• Align vehicle configuration
• Guided Functions

For the full list of functionalities, see Technical Specification tab.

Specifications:

Calibration

• (CCU) Accleration Zero
• (CCU) Suspenssion Pressure Sensor Calibration
• (SCML/SMCR) Seat Calibration
• (SAS) Zero Position Steering Wheel (Fine Tuning)
• (ESP) Yaw Rate Sensor Calibration
• (SCUG) Steering Column Calibration
• (DMR/DML)Door Windows Calibration

Diagnostic tests

• (ADI) Speaker System Test
• (ADI) Speaker Out Test
• (CCU) Adaptive Damping Config
• (ECM) Cam Control Diagnostics
• (ECM) Catalytic Converted Diagnostics
• (ECM) Purge System Diagnostics
• (ECM) Throttle Adaptations Clear/Save
• (ECM) Secondary Air Diagnostics
• (HVAC) Sensor Electrical Test

Reset

• (PCCU/TCU) Gear Adaptations Reset
• (PCCU/TCU) Clutch Adaptations Reset
• (TPMS) TPMS Factory Reset
• (ADI/IC) ADI Default Configuration Restore (and Erase)

Configurations

• (ADI) Radio Configuration
• (BC) Heated Screen Configuration
• (ESP) Dynamometer Mode Enable

VIN change available for:

• ADI
• BC
• CCU
• CRCM
• ECU
• EISB
• EPHS
• ESP
• FMW
• IBS
• IC
• MCU
• ORC
• PCCU
• PTCU
• PDCU
• SBC
• SCML
• SCUG
• TCU
• TPMS

Engine-related guided functions:

• Catalytic Converter Diag
• Purge System Diagnostic
• Secondary Air Diag
• Cam Control Diagnostics
• DMTL Leakage Test

Engine calibration-type guided functions:

• Throttle Adaptation
• Save Throttle Adaptations
• Clear Misfire Calibration

TCU/PCCU calibrations and adaptations:

• [TCU] Air Brake Bleed
• [TCU] Air Brake Calibration
• [TCU] Calibration
• [TCU] Transmission Warmup
• [TCU] Replacement Reset
• [TCU] Synchro Adaptation
• [TCU] Turbo Wastegate Control
• [TCU] Hydraulic Contamination Cleaning
• [TCU] Clutch1/2 Kisspoint Adaptation
• [TCU] Clutch1/2 Preload Adaptation
• [TCU] Clutch1/2 Pressure Current Adaptation
• [TCU] Clutch1/2 Fill Volume Adaptation
• [TCU] Clutch1/2 Fast Fill Volume Adaptation
• [TCU] Line Pressure Adaptation
• [PCCU] Dual Clutch Calibration
• [PCCU] Hydraulic Contamination Cleaning
• [PCCU] Nose lift Maintenance
• [PCCU] Nose Sensor Lift Calibration
• [PCCU] Clear Gear Adaptations
• [PCCU] Damping Sensor Calibration

Supported vehicles:

• McLaren MP4-12C
• McLaren 540C
• McLaren 570S
• McLaren 600LT
• McLaren 650S
• McLaren 625C
• McLaren 620R
• McLaren 675LT
• McLaren 720S
• McLaren 750S
• McLaren 765LT
• McLaren Elva
• McLaren Senna
• McLaren GT
• McLaren Speedtail
• McLaren P1
• And all variations of the models listed above (Spyder, GTR, etc.)
