ABRITES - FN015 - Engine Control Unit Configuration Manager

ABRITES - FN015 - Engine Control Unit Configuration Manager

The FN015 is dedicated to reading and updating ECU's internal configuration memory for Fiat/Lancia/Alfa/FCA (FIAT/CHRYSLER AUTOMOBILES) vehicles by OBD.

Functionalities:

• Read/update ConfData by OBD
• Calibration by OBD
• Make VIRGIN by OBD

(When not possible to work by OBD, boot mode is required)

Supported Units:

• BOSCH: EDC15C5 EURO2, EDC15C7 EURO3, ME7.3H4 (BOOT MODE), ME7.3.1 (BOOT MODE)
• MARELLI: IAW 4AF, IAW 4EF, IAW 59F, IAW 59M, IAW 5AF (HW30x, ST10F168), IAW 5AF (HW60x, ST10F269), IAW 5AM, IAW 5NF, IAW 5SF3/5SF8 (Kline), IAW 5SF3 (CAN), IAW 5SF8 (CAN), IAW 5SF9 (CAN), 8GMF, 8GMK, 8GSF, 8GSW/ and GMW, 9GF, MJD 6JF (Kline), MJD 6F3 (Kline), MJD 6F3 (CAN), MJD 8F2 (Kline), MJD 8F2 (CAN), MJD 8F3 (CAN), MJD 9DF

Supported Models Include:

• ALFA: 145 - 1.9 JTD, 146 - 1.9 JTD, 147 - 1.9 JTD 16V; 1.9 JTD 8V, 156 - 1.9 JTD; 2.4 JTD, 166 - 2.4 JTD and others.
• FIAT: Bravo - 1.9 JTD, Brava - 1.9 JTD, Doblo - 1.9 JTD, Ducato - 2.0 JTD; 2.3 JTD; 3.8 JTD, Marea - 1.9 JTD; 2.4 JTD, Marengo - 1.9 JTD, Fiat Punto - 1.9 JTD, Palio - 1.9 JTD, Stilo - 1.9 JTD, Siena - 1.9 JTD, Scudo - 2.0 JTD and others.
• FIAT: New Panda, Idea, Doblo, Punto, Grande Punto, Cinquecento (with 1.3 IAW MultiJet MJD 6JF)
• LANCIA: K - 1.9 JTD, Lybra - 1.9 JTD, 2.4 JTD, Thesis - 2.4 JTD, Z - 1.9 JTD and others; Musa, Ypsilon (with 1.3 IAW MultiJet MJD 6JF)

An AVDI interface with an active annual subscription is required.
